Wired IEM Systems
FISCHER AMPS HARDWIRED IN-EAR
Option:
Wired IEM
Description
Features
Two direct symmetric XLR inputs (no special cable required)
Much better sound than wireless in ear systems
Switch-over from stereo to mono-mix mode
2 x 40mW power with limiter
Control for volume and pan/mix
Sturdy aluminium case, holder of stainless steel
Mains connector (lockable) for plugging in an external DC mains adapter (optional extra)
Power supply with 9V block battery.
Hours of operation with alkaline battery approx. 12h, with rechargeable battery approx. 8h.
Specifications
Dimensions L x W x H (in mm):
127 x 82 x 30
Weight:
290 g
Input connectors:
2 x Neutrik XLR jack 3-pole, with interlock
Earphone connector:
1/8" mini connector
Frequency response:
30 Hz - 20 KHz +/- 2 dB
Minimum impedance of earphones:
12 ohms per side
Input impedance:
15kohms
Nom. input level:
0dB - +4dB (limiter at +5dB)
Nom. input level symetric:
0 dBV
Max. Einput level symmetric:
+4 dBV
Limit input level symmetric:
+5 dBV
Max output power at 20 ohms:
40 mW per channel
Max. operating current:
40 mA
Power supply:
9V block alkaline battery or 8.4V rechargeable battery NiMH
DC-input plug:
ext. input power DC 9V (pin +, ring -)
Operating time of battery:
approx. 8h with 270mAh rechargeable battery, approx. 12h with alkaline battery (depends on headphones volume)
