MACKIE 1604VLZ3

Description

Don't let its size fool you. The Mackie 1604-VLZ3 mixer is packed with premium features on every channel; 75Hz Low-Cut filters, four Aux Sends, inserts, phantom power, constant-loudness Pan controls, OL (overload) and signal present LEDs, sub and main mix assign switches, and assignable AFL/PFL Solo switch. And since you can never have too many output options, we provided a Control Room/Phones source matrix, Master Aux section with EFX to Monitor, tape outputs, high-volume headphone amplifier, channels 1-8 direct outs, and balanced XLR and balanced/unbalanced TRS outputs.

Features:-

New ultra-low noise VLZ3 design with highest possible headroom
16 studio-grade XDR2™ Extended Dynamic Range mic preamps with:
- Ultra-wide 60dB gain range
- 130dB dynamic range
- +22dBu line input handling
- Extended low frequency response
- Distortion under 0.0007% (20Hz - 20kHz)
- Phantom power for studio condenser mics
16 high-headroom line inputs, 16 channel inserts
Advanced DC pulse transformer RF rejection
60mm long-wearing logarithmic-taper faders
4 Aux sends, level, pan, -20dB/Solo and Overload/Mute_LEDs on each channel
4 stereo Aux returns, 8 Direct outs, 4 Group/Bus outputs
3-band Active EQ with sweepable midrange
18dB/oct. 75Hz Lo-Cut filter
Control Room/Phones multi-input source matrix
Balanced 1/4" inputs and outputs (except inserts)
Rack-mountable design with three physical configurations via rotating I/O pod
Sealed rotary controls to resist dust and grime
New Multi-Voltage power supply for worldwide use
Rugged steel chassis
