The Artist Elite AE3000 delivers supreme performance at extreme SPLs. This high-SPL large diaphragm cardioid condenser instrument mic excels in applications such as guitar cabinets, toms, snare, timpani, horns and overheads. Its large-diaphragm capsule combines with the open architecture of the headcase to provide an extremely accurate and open sound. Its low-profile side-address design with tapered grille allows for optimal positioning.
Specifications:
- Element: Fixed-charge back plate, permanently polarized condenser
- Polar Pattern: Cardioid
- Frequency Response: 20-20,000 Hz
- Low Frequency Roll-Off: 80 Hz, 12 dB/octave
- Open Circuit Sensitivity: -43 dB (7.0 mV) re 1V at 1 Pa
- Impedance: 100 ohms
- Maximum Input Sound Level: 148 dB SPL, 1 kHz at 1% T.H.D.; 158 dB SPL, with 10 dB pad (nominal)
- Noise: 11 dB SPL
- Dynamic Range (Typical): 137 dB, 1 kHz at Max SPL
- Signal-To-Noise Ratio:83 dB, 1 kHz at 1 Pa
- Phantom Power Requirements: 11-52V DC, 3 mA typical
- Swithces: High-pass filter; 10 dB pad (nominal).
